Under Counter Refrigeration

Name: Under Counter Refrigeration
Brand: ICE MAKE REFRIGERATION LIMITED
Price: 49000 INR
Availability: InStock

Price 49000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Under Counter Refrigeration Specification

Type
Under Counter Refrigeration

Material
Stainless Steel Body

Power
200 Watts Watt (w)

Power Source
Electric

Voltage
220 Volt Volt (v)

Capacity
200 Liters Ltr

Loading Capacity
200 Liters Long Ton

Automatic Defrost Operation
Yes

Operating Temperature
2C to 8C Celsius (oC)

Temperature Range
2C to 8C Celsius (oC)

Dimension (L*W*H)
1200 mm x 700 mm x 850 mm Millimeter (mm)

Weight (kg)
80 Kg Kilograms (kg)

Color
Silver

Under Counter Refrigeration Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
10 Units Per Month

Delivery Time
1 Months

About Under Counter Refrigeration

With the help of a dedicated workforce, we are able to manufacture, supply and export Under Counter Refrigeration. These products are known in the market for their compact size and custom panels. In order to ensure their supreme quality, these products are checked duly by our team of skilled and trained quality analyzers. Longer service life, low maintenance, high strength, better workability and resistance against corrosion are some of the main features of these products. Under Counter Refrigeration is delivered to the clients in a stipulated time frame owing to our expert logistics team.

Specifications:

Under Counter Refrigeration / Pantry Freeze / Prep Tables with Refrigeration

Temperature :^oC
Application for :Take your operation to the next level in Food prep by utilizing the benefits of UCR, widely used in Hotels, Restaurants, Bars, Fast Food Chains
Length :3 feet to 7.5 feet in Length

Body Type :

Body Material :

G.I. Pre Painted Sheet,Colour White, Thickness 0.55 mm
S.S.Sheet, Grade 202, 430, 304, 316, Thickness 0.50 to 1.2 mm, Finish 2 B (original). Mirror, Mate
Base Frame M.S. or S.S. Angel, with S.S. leg or castor wheel

Salient Features

Outer, Top & Door S.S. 202-0.55mm, Inner S.S.304-0.55mm.

Insulation :

Thickness 60 to 75mm, Insulatio nPoly Urethen Foam (PUF) CFC free. Density 38 Kg /M3,+/-2 kg, all Body PUF pouring by automatic Imported make (SAIP) machines

Compressor :

Hermetic type with suction gas cooled motor, equipped with over load protector. We provide world's best compressor Copeland, Danfoss, Tecumseh

Fan Motor :

Propeller type (Quite) we choose only top brand like EIco, EBM, AUE, ELCO

Refrigerant :

R-134a, R-404 CFC free & R-22

Power Supply :

230 Volts, 10%+,50Hz, I Ph/440 Volts 10%+, 50 Hz, 3 Ph

Salient Features

Designed to suit local conditions made tough compared to other local & imported / Standard manufacturers.
All appliances can be made as per client's specification on demand.
Our appliances are tested for well balance system design, energy, efficient, long lasting performance and maintenance free.

Temperature: 0^oC

Model	Size in inch LxHxW	Door	Compressor model	Pans 1/6x100 mm QTC	Pans 1/9x100 mm QTC
IU-3.0/90	36x24x33	1	KCN 396	2	4
IU-3.5/170	42x28x33	1	KCN 396	2	6
IU-4.0/210	48x28x33	1	KCN 396	3	7
IU-4.5/260	54x28x33	1	KCN 411	3	8
IU-5.0/315	60x28x33	2	KCN 444	4	8
IU-5.5/360	66x28x33	2	KCN 463	5	8
IU-6.0/420	72x28x33	2	KCN 463	6	10
IU-6.5/475	78x28x33	2	KCN 463	6	10
IU-7.0/520	84x28x33	3	KCN 423	6	12
IU-7.5/570	90x28x33	3	KCN 423	7	12

Precision Cooling for Professional Kitchens

The under counter refrigeration unit offers precise temperature management thanks to a digital controller, keeping perishables at a stable 2C to 8C. The efficient hermetically sealed compressor and advanced polyurethane foam insulation result in lower energy consumption, quieter operation, and long-lasting freshness of stored products. Its floor-standing design and compact dimensions allow for seamless integration into busy kitchen spaces.

Durable Construction and Flexible Storage

Crafted from stainless steel, this refrigerator is built to endure the rigors of commercial environments. Featuring adjustable stainless steel shelves, it allows users to customize the storage layout for food items of varying sizes. Solid doors provide extra protection for stored goods, while LED internal lighting ensures clear visibility, even during busy service hours.

FAQs of Under Counter Refrigeration:

Q: How does the digital temperature controller benefit the refrigeration process?

A: The digital temperature controller provides accurate and consistent temperature regulation between 2C and 8C. This ensures all stored items stay at optimal freshness and safety levels, crucial for commercial kitchens and foodservice businesses.

Q: What makes the hermetically sealed compressor suitable for commercial use?

A: A hermetically sealed compressor is highly efficient and reliable, minimizing maintenance needs while offering quieter operation (below 45 dB). This is essential in a professional environment where performance and atmosphere matter.

Q: When should the adjustable stainless steel shelves be repositioned?

A: You can adjust the stainless steel shelves whenever you need to accommodate items of different heights or sizes. This flexibility maximizes usable space and helps organize refrigerated goods efficiently.

Q: Where is the ideal placement for this under counter refrigerator?

A: This unit is designed as a floor-standing refrigerator and fits seamlessly under counters or workbenches in commercial kitchens, making it accessible while saving valuable workspace.

Q: What is the benefit of automatic defrost operation in daily use?

A: Automatic defrost ensures that ice buildup is minimized without manual intervention, maintaining consistent cooling performance and reducing maintenance for busy staff.

Q: How does polyurethane foam insulation improve refrigeration efficiency?

A: Polyurethane foam insulation greatly reduces heat transfer, keeping cold air inside the unit more effectively. This improves energy efficiency and ensures stable cooling, crucial for food preservation.

Technical Details
