Refrigerated van

Name: Refrigerated van
Brand: ICE MAKE REFRIGERATION LIMITED
Price: 515000.00 INR
Availability: InStock

Price 515000.00 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Refrigerated van Specification

Material
Insulated Sandwich Panels (PUF/GRP)

Type
Refrigerated Van

Style
Box Type

Refrigerant
R134a or R404A

Climate Type
Tropical/All Climate

Temperature
-20C to +10C adjustable

Power
0.7 to 3.0 KW

Voltage
12V/24V DC or 220V AC

Capacity
2 to 15 Tons

Layer
3 (Inner lining, Insulation, Outer body)

Refrigerated van Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
10 Units Per Month

Delivery Time
1 Months

About Refrigerated van

ICE MAKE Eutectic Mobile Container is designed for multi drop Ice cream, Frozen Foods, Bakery Products and Fruits & Vegetables distribution

Assured refrigeration performance with total reliability
Superfast temperature pull down up to -24^oC
Suitable for multiple Deliveries door openings
Unique Eutectic Plate design offers maximum Heat Transfer surface area
Non-toxic gel filled in sealed pack - which will not leak

Ice make: Eutectic system are designed to operate in vehicles that have been suitably insulated for fresh of forzen produce transportation. The Eutectic plates are mounted inside a chamber which is separate from the main load system. The product inside the storage compartment is cooled on required temperature either for frozen application (-24^oC) OR CHIKKED APPLICATION (+2^oC to 8^oC) by the PCM pads. The connected power supply to charge should be 3 phase.

Specification:

Insulation Thickness :	For Frozen Application : 100 mm + 25 mm (Eutectic Plate) For Chilled Application : 80 / 100 mm + 25 mm (Eutectic Plate)
Refrigeration System :	Air Cooled With Electric Support
Compressor Type :	Semi shield / Scroll compressor
Unit Running Time :	For Frozen Application : 10 to 12 Hr. For Chilled Application : 4 to 5 Hr.
Temperature :	For Frozen Application : -24^oC after charging & -12^oC after 12 To 14 Hr. For Chilled Application : 0^oC after charging & +4^oC after 4 to 5 Hr.
Back up time :	For Frozen Application : 12 to 14 Hr. For Chilled Application : 4 to 5 Hr.

	Eutectic Mobile Container	Diesel Engine operated container
Vehicle engine maintenance	Less (No load on Vehicle Engine)	High (Run by only vehicle engine)
Reefer Unit Maintenance	Easy available & Repair by local technical	Repair by companies technician & High cost
Carbon emission by Reefer unit	Zero	High

Superior Insulation for Maximum Freshness

The vans three-layer construction, including high-quality PUF insulation up to 120mm thickness, limits heat ingress and ensures consistent internal temperatures. This is critical for transporting perishable goods over long distances in diverse climates. Custom insulation options allow operators to tailor performance for specific cargo needs.

Flexible and Reliable Cooling Systems

Equipped with renowned compressors such as Emerson, Danfoss, or Tecumseh, the van adapts to different operational conditions. Its cooling system supports direct drive or independent units, functioning on 12V/24V DC or 220V AC. Temperatures are adjustable, ranging from deep freeze to moderate cooling, suitable for broad usage scenarios.

Built for Hygiene and Safety

A food-grade GRP or stainless steel inner lining combines with an anti-slip aluminum or stainless steel floor to meet rigorous industry hygiene standards. The vans design makes sanitization straightforward, ensuring goods are transported in a safe environment, free from contamination risks.

FAQs of Refrigerated van:

Q: How does the insulation thickness impact the refrigerated vans performance?

A: The insulation thickness, ranging from 65mm to 120mm using PUF panels, significantly enhances thermal efficiency. Thicker insulation minimizes temperature fluctuations, preserving product quality throughout transit, especially in tropical or variable climates.

Q: What process is involved in customizing the van chassis for different commercial vehicle brands?

A: Customization begins with assessing the specific chassis requirements of your selected commercial vehicle brand. The van body is then tailored with matching mounting systems and electrical configurations, ensuring seamless integration and optimal functioning of refrigeration units.

Q: When is it necessary to choose between a direct drive and an independent cooling unit?

A: A direct drive cooling system is preferred when the vans engine provides uninterrupted power, suitable for short deliveries. However, for extended stops or multi-drop routes, an independent unit maintains internal temperatures without relying on engine operation, guaranteeing cargo safety.

Q: Where can this refrigerated van be utilized for transportation?

A: This van serves a wide range of industries, including food distribution, dairy transport, pharmaceutical logistics, and frozen goods delivery. Its compatibility with most commercial vehicle brands makes it suitable for operations throughout India and beyond.

Q: What are the benefits of having a food-grade GRP or stainless steel inner lining?

A: A food-grade GRP or stainless steel lining safeguards cargo against contamination, supports easy cleaning, and complies with safety regulations for transporting food, dairy, and medicine. This enhances both hygiene and product integrity during transit.

Q: How is the temperature adjusted inside the van for different cargo requirements?

A: Temperature settings from -20C to +10C are easily managed through a user-friendly control panel, making it simple to tailor conditions for frozen, chilled, or ambient cargo based on specific transport requirements.

Q: What makes the van suitable for use in tropical or all climate conditions?

A: Robust insulation, high-performance compressors, ultraviolet-resistant exterior finishes, and adaptable cooling systems ensure consistent operation across all climate zones. This versatility protects goods during transit in Indias varied environments.
