Product Code : 0001

Brand Name : ICE MAKE

Product Description

ICE MAKE – Eutectic Mobile Container is designed for multi drop Ice cream, Frozen Foods, Bakery Products and Fruits & Vegetables distribution

Assured refrigeration performance with total reliability
Superfast temperature pull down up to -24°C
Suitable for multiple Deliveries door openings
Unique Eutectic Plate design offers maximum Heat Transfer surface area
Non-toxic gel filled in sealed pack - which will not leak

Ice make: Eutectic system are designed to operate in vehicless that have been suitably insulated for fresh of forzen produce transportation. The Eutectic plates are mounted inside a chamber which is separte from the main load system. The product inside the storage compartment is cooled on required temperature either for frozen application (-24ºC) OR CHIKKED APPLICATION (+2ºC to 8ºC) by the PCM pads. The connected power supply to charge should be 3 phase.

Specification:

Insulation Thickness :	For Frozen Application : 100 mm + 25 mm (Eutectic Plate) For Chilled Application : 80 / 100 mm + 25 mm (Eutectic Plate)
Refrigeration System :	Air Cooled With Electric Support
Compressor Type :	Semi shield / Scroll compressor
Unit Running Time :	For Frozen Application : 10 to 12 Hr. For Chilled Application : 4 to 5 Hr.
Temperature :	For Frozen Application : -24°C after charging & -12°C after 12 To 14 Hr. For Chilled Application : 0°C after charging & +4°C after 4 to 5 Hr.
Back up time :	For Frozen Application : 12 to 14 Hr. For Chilled Application : 4 to 5 Hr.

	Eutectic Mobile Container	Diesel Engine operated container
Vehicle engine maintenance	Less (No load on Vehicle Engine)	High (Run by only vehicle engine)
Reefer Unit Maintenance	Easy available & Repair by local technical	Repair by companies technician & High cost
Carbon emission by Reefer unit	Zero	High
