Ice Candy Plant

Ice Candy Plant

Product Code : ICP11

Brand Name : ICE MAKE

Product Description

We manufacturing wide range of ice candy production machine using high quality material & advance technology which to be used to produce ice candy.

Specification

Model	ICCP-4	ICCP-6	ICCP-9	ICCP-15
Capacity/Hr	192 candy	288 candy	432 candy	720 candy
Outer size in inch (L x W x H)	53” x 25” x 26.5”	66” x 32” x 26.5”	77” x 32” x 26.5”	114” x 32” x 26.5”
Inner Tank size in inch (L x W x H)	47” x 19” x 23.5”	60” x 26” x 23.5”	71”x 26”x 23.5”	108” x 26” x 23.5”
Using Size	32” x 19”x 8”	48” x 26” x 8”	55” x 26” x 8”	90” x 26” x 8”
Power Input(kw)	3.0	4.1	5.4	8.6
Brine Storage Capacity approx.	300 Ltrs	510 Ltrs	600 Ltrs	920 Ltrs

Model	ICCP-20	ICCP-32	ICCP- 40
Capacity/Hr	960 Candy	1536 Candy	1920 Candy
Outer size in inch (L x W x H)	114” x 38” x 26.5”	168” x 38” x 26.5”	202” x 38” x 26.5”
Inner Tank size in inch (L x W x H)	108” x 32 x 23.5”	162” x 32” x 23.5”	196” x 32” x 23.5”
Using Area in inch (L x W x H)	90” x 32” x 8”	144” x 32” x 8”	180” x 32” x 8”
Power Input(kw)	10.6	16.9	20.2
Brine Storage Capacity approx.	1130 Ltrs	1700 Ltrs	2060 Ltrs

Application : Ice Candy, Roll Cut Ice cream Production
Temperature :-26°C to -30°C
Body :Outer- S.S. Grade 304, Inner- S.S Grade 316,
Pull Down Time :Ice cream base (Output from CF, freezer) hardening time 20 to 30 minute approx. Water base flavor hardening time 30 to 35 minute approx. (Mix Inlet temp - +10°Cto +14°C)
Conditions : Mix Inlet temp must be -4°C or lower, Water flow rate as per required capacity in case of water cooled system.
