Home » Products » Vertical Freezer - Chiller » Under Counter Refrigerator and Pantry Freeze

Under Counter Refrigerator and Pantry Freeze

Under Counter Refrigerator and Pantry Freeze
Under Counter Refrigerator and Pantry Freeze
Product Code : 23
Brand Name : ICE MAKE
Product Description

We are offering of Under Counter Refrigerator and Pantry Freeze.

Product details:

Temperature

2°C to 8°C

Body Type

Q

Application for

Take your operation to the next level in Food preparation by utilizing the benefits of UCR, widely used in Hotels, Restaurants, Bars, Fast Food Chains

Length

3 feet to 7.5 feet in Length

Technical Specification

Insulation

Thickness 60 to 75mm, Insulation PolyUrethane Foam (PUF) CFC free. Density 38 Kg /M3,+/-2 kg, all Body PUF pouring by automatic Imported make (SAIP) machines

Compressor

Hermetic type with suction gas cooled motor, equipped with over load protector. We provide world's best compressor Copeland, Danfoss, Tecumseh

Fan Motor

Propeller type (Quite) we choose only top brand like EIco, EBM, AUE, ELCO

Refrigerant

R-134a, R-404 CFC free & R-22

Power Supply

230 Volts, ?10%,50Hz, I Ph/440 Volts ?10%, 50 Hz, 3 Ph

Salient Feature:

  • Designed to suit local conditions made tough compared to other local & imported / Standard manufacturers.

  • All appliances can be made as?per client's specification on demand.

  • Our appliances are tested for well balance system design, energy, efficient, long lasting performance and maintenance free.

Temperature: 0ºC

Model

Size in inch LxHxW

Door

Compressor model

Pans 1/6x100 mm QTC

Pans 1/9x100 mm QTC

IU-3.0/90

36x24x33

1

KCN 396

2

4

IU-3.5/170

42x28x33

1

KCN 396

2

6

IU-4.0/210

48x28x33

1

KCN 396

3

7

IU-4.5/260

54x28x33

1

KCN 411

3

8

IU-5.0/315

60x28x33

2

KCN 444

4

8

IU-5.5/360

66x28x33

2

KCN 463

5

8

IU-6.0/420

72x28x33

2

KCN 463

6

10

IU-6.5/475

78x28x33

2

KCN 463

6

10

IU-7.0/520

84x28x33

3

KCN 423

6

12

IU-7.5/570

90x28x33

3

KCN 423

7

12
