Super Market Display Cabinets
Super Market Display Cabinets
<<Previous
Product Description
Suitable for super market to display Dairy items, Cake-Pastry, Chocolates, Beverages, Fruits & Vegetables, Flowers & Medicines etc
Special feature
- Large storage with Better Display Area
- Custumised size
- Temperature retaining
- Energy efficient
- Easy maintenance
- Easy assemble & dismantle
- Temperature: 2 to 8 ° C
Technical specification
- Glass door opening size: 711mmx1956mm
- Customized glass doors (hinged type) with magnetic door gasket for air tight seal
- Floor insulation: Aluminium checkered plate
- Digital temperature controller with digital display
- Insulated perimeter frames designed with forward facing for easier servicing and maintenance from front of the door
- Energy efficient frame that reduce energy to the frame by 30% with added insulation resulting in the same
- Double layer vaccumized tempered glass for moisture
- Adjustable shelving system for specific arrangement of products
- Provision for special demands such as glass doors, special floor, slient condensing unit, shelving system, etc.
- Long durable and perfect construction with balanced refrigeration system
Available glass door display chiller size
| Display area | |||
| No of door | Chiller size (LxWxH) | Volume CFT | Connected power |
| 2 | 65.5”x47”x99” | 126 | 1 / 3 phase, 1.85kw |
| 3 | 98.75”x47”x99 | 201 | 1 / 3 phase, 1.68kw |
| 4 | 127.5”x47”x99 | 264 | 1 / 3 phase, 1.68kw |
| 5 | 156.25”x58.5”x9” | 419 | 1 / 3 phase, 2.17kw |
| 6 | 185”x58.5”x99” | 499 | 1 / 3 phase, 2.17kw |
| Display with storage area | |||
| No of door | Chiller size (LxWxH) | Volume CFT | Connected power |
| 2 | 65.55” x 93” x 99” | 269 | 1 / 3 phase, 1.68 KW |
| 3 | 98.25” x 93” x 99” | 429 | 1 / 3 phase, 1.68 KW |
| 4 | 127.05” x 93” x 99” | 563 | 1 / 3 phase 2.17kw |
| 5 | 156.25” x 93” x 99” | 696 | 3 phase, 3.26kw |
| 6 | 185” x 93” x 99” | 829 | 3 phase, 3.26kw |
