Ice Cream Cold Room

Ice Cream Cold Room
Ice Cream Cold Room
Product Code : ICCR02
Brand Name : ICE MAKE
Product Description

Our reputation in the market is largely attributable to our precision-designed Ice Cream Cold Room. This cold room is designed using exceptional quality components and latest technology by our accomplished professionals. In order to ensure its quality and performance, offered cold room is strictly examined on various parameters by our quality experts. We manufacture this cold room to suit every chilling application. Our offered Ice Cream Cold Room is available in flush type swing door with FRP profile, imported hardware, push type Gasket and replaceable heater for easy door operation and long life.

Features:

  • Optimum quality
  • Easy installation
  • User friendly operations
  • Longer life

Technical Specifications :

Thickness 60,80,100,125 and 150mm
Surface material GI pre-painted sheet, S.S sheet (Grade 304/316), GI Plain sheet, Galvanium (Inside and outside different metal can be placed as per your requirement)
Floor For Kota stone or concrete floor, puf slab with both side tar felt coated
For kota stone or concrete floor, both side metal surface panel in which each side fits with cam lock and prevent temperature loss
Aluminium chequered plate with marine ply
FRP clading on floor
Door Flush type: Swing door with FRP profile, imported hardware, push type Gasket and replaceable heater for easy door operation and long life
Size: 24x66, 30x72, 34x78, 45x84 (Door opening WxH)
Over lap type: Teak wood frame with metal covering by using heavy duty hardware for better strength
Size: 45x84, 49x84, 54x84, 60x90 (Door opening WxH)
Room size Length and width minimum 1.78mt and bigger size 0.146 mt in multiples. As per requirement
Standard height for 60mm thickness 2.47mtr, 80mm-2.51mt, 100mm-2.55mt, 125mm-2.60mt, 150mm-2.65mt. Single panel height up to 6.25mt and above as per your requirement

Accessories

Flush type door

Flush type doors are fitted with push type gasket, PVC profile & replicable electrical wire heater for smooth door operation.

Hatch door

Hatch doors are available in different sizes and are fitted with heavy frame for easy movement. These are hugely demanded by dairy industries and high turnover ice cream factories.

Pressure ventilator

To balance the pressure & vacuum inside the cold room, tri-action pressure ventilator with/with out heater is used.

View port

Three layer argon packed toughen glass equipped with 12x12 view port can be visible inside the cold room having -20oC temperature.

Strip curtain

To prevent heat loss, semi transparent PVC strip curtain with negative temperature application is used.

Ramps

Ramps are used for easy & effortless movement of the trollies without damaging the door frame.
